Hemi Metals, based in Hamilton, New Zealand, stands out as a trusted manufacturer and supplier of top-notch Incoloy Bright Bars, celebrated for their precision, durability, and exceptional performance even in tough industrial settings. Thanks to their advanced manufacturing techniques and rigorous quality control, the company produces bright bars that adhere to international standards for corrosion resistance, strength, and surface finish. These Incoloy Bright Bars are designed to maintain excellent stability at high temperatures, ensuring long-lasting reliability in demanding applications. Hemi Metals is dedicated to customer satisfaction, offering timely delivery, technical support, and consistent product quality for industries like petrochemical, marine, power generation, and engineering, both in New Zealand and around the globe.
Incoloy Bright Bars primarily consist of nickel, chromium, and iron, with certain grades enhanced by the addition of molybdenum, copper, aluminum, and titanium to boost their resistance to oxidation and chemical damage. These bars are known for their high tensile strength, impressive toughness, and strong resistance to creep when exposed to prolonged high temperatures. Their smooth, bright finish not only enhances dimensional accuracy but also improves surface quality, making them ideal for precision components. With remarkable resistance to carburization, oxidation, and chloride-induced corrosion, Incoloy Bright Bars maintain their structural integrity even in extreme thermal and chemical conditions.
| Dimensions | BS, DIN, EN, AISI, JIS, ASME, ASTM |
|---|---|
| Size of Round Bars | Thickness: 2 milimeter-100 milimeter |
| Surface | Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished |
| Processing | cutting to 650 milimeter |
| Tolerance | H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need |
| Finish | centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black |
| Method | Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars |
| Condition | annealed, Hardened & tempered |
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
|---|---|---|---|---|---|---|---|
| Diam. (Inch) | Bar Size | Diam. (mm) | Bar Size | Diameter (mm) | Bar Size | Diameter (mm2) | Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | ||
| 1.375 | #11 | 14 | 14 | 35 | 35 | ||
| 1.500 | #12 | 16 | 16 | 38 | 38 | ||
| 1.625 | #13 | 18 | 18 | 41 | 41 | ||
| 1.750 | #14 | 20 | 20 | 44 | 44 | ||
| 1.875 | #15 | 22 | 22 | 48 | 48 | ||
| 2.000 | #16 | 25 | 25 | 51 | 51 | ||
| 2.250 | #18 | 28 | 28 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot |
|---|---|---|---|---|---|---|---|---|
| 1/8″ | 0.062 | 0.019 | 22mm | 2.979 | 0.908 | 3-1/4″ | 41.996 | 12.800 |
| 3mm | 0.055 | 0.017 | 20mm | 2.470 | 0.753 | 3″ | 35.762 | 10.900 |
| 4mm | 0.098 | 0.030 | 24mm | 3.543 | 1.080 | 3-3/4″ | 55.780 | 17.001 |
| 5/32″ | 0.095 | 0.029 | 7/8″ | 3.038 | 0.926 | 3-1/2″ | 48.772 | 14.850 |
| 5mm | 0.154 | 0.047 | 1″ | 3.970 | 1.210 | 4-1/4″ | 72.249 | 21.908 |
| 3/16″ | 0.141 | 0.043 | 25mm | 3.871 | 1.180 | 4″ | 63.340 | 19.306 |
| 6mm | 0.223 | 0.068 | 27mm | 4.490 | 1.368 | 4-3/4″ | 90.249 | 27.366 |
| 7/32″ | 0.190 | 0.058 | 26mm | 4.170 | 1.271 | 4-1/2″ | 80.340 | 24.4487 |
| 7mm | 0.298 | 0.091 | 30mm | 5.548 | 1.691 | 5-1/2″ | 121.000 | 36.690 |
| 1/4″ | 0.249 | 0.076 | 1-1/8″ | 5.033 | 1.534 | 5″ | 99.940 | 30.461 |
| 8mm | 0.398 | 0.120 | 32mm | 6.314 | 1.894 | 6-1/2″ | 167.630 | 51.093 |
| 5/16″ | 0.387 | 0.118 | 1-1/4″ | 6.349 | 1.924 | 6″ | 143.900 | 43.860 |
| 3/8″ | 0.557 | 0.170 | 35mm | 7.553 | 2.390 | 7-1/2″ | 225.000 | 68.226 |
| 9mm | 0.498 | 0.152 | 1-3/8″ | 7.550 | 2.303 | 7″ | 196.000 | 59.432 |
| 11mm | 0.748 | 0.228 | 38mm | 8.903 | 2.792 | 10″ | 397.140 | 121.048 |
| 10mm | 0.620 | 0.189 | 36mm | 7.999 | 2.438 | 8″ | 254.55 | 77.586 |
| 12mm | 0.889 | 0.271 | 40mm | 9.872 | 3.009 | |||
| 7/16″ | 0.761 | 0.232 | 1-1/2″ | 8.951 | 2.715 | |||
| 13mm | 1.043 | 0.318 | 1-3/4″ | 12.179 | 3.712 | |||
| 1/2″ | 0.994 | 0.303 | 1-5/8″ | 10.449 | 3.200 | |||
| 9/16″ | 1.256 | 0.383 | 1-7/8″ | 13.977 | 4.260 | |||
| 14mm | 1.207 | 0.368 | 45mm | 12.555 | 3.807 | |||
| 5/8″ | 1.551 | 0.473 | 50mm | 15.414 | 4.698 | |||
| 15mm | 1.391 | 0.424 | 48mm | 14.205 | 4.330 | |||
| 17mm | 1.791 | 0.543 | 2-1/8″ | 17.963 | 5.475 | |||
| 16mm | 1.578 | 0.481 | 2″ | 15.906 | 4.848 | |||
| 18mm | 2.001 | 0.610 | 60mm | 22.205 | 6.768 | |||
| 11/16″ | 1.880 | 0.573 | 2-1/4″ | 20.128 | 6.135 | |||
| 3/4″ | 2.237 | 0.682 | 2-3/8″ | 22.435 | 6.838 | |||
| 2-1/2″ | 24.856 | 7.576 | ||||||
| 2-5/8″ | 27.409 | 8.354 | ||||||
| 2-3/4″ | 30.083 | 9.169 | – | – | – |
Incoloy bright bars offer excellent corrosion resistance, high-temperature strength, durability, oxidation resistance, and versatility in extreme environments.
Incoloy bright bars generally have excellent corrosion resistance due to their alloy composition, reducing the need for additional protective coatings. However, in highly aggressive environments, extra coatings or surface treatments may be applied for enhanced protection.
These bars find extensive use in industries that demand superior corrosion resistance, strength, and dependable performance. They’re commonly utilized in the production of heat exchanger components, furnace fittings, petrochemical processing equipment, boiler parts, and machinery for chemical plants. Their bright finish and excellent machinability make them perfect for precision shafts, fasteners, valves, and instrumentation parts. In marine and offshore settings, these bars effectively resist saltwater corrosion. Additionally, they play a crucial role in power generation systems, refineries, and high-temperature processes.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hemi Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Hamilton New Zealand
