Hemi Metals, located in Hamilton, New Zealand, has built a solid reputation as a reliable manufacturer and supplier of high-performance Alloy C263 Bars and Rods. These products are celebrated for their remarkable strength, resistance to oxidation, and stability even in high-temperature settings. Thanks to cutting-edge production techniques and rigorous quality control, Hemi Metals ensures that their Alloy C263 offerings meet the stringent demands of industries like aerospace, gas turbines, and high-stress manufacturing. With outstanding creep resistance and excellent metallurgical consistency, these bars and rods are perfect for precision-engineered components. Customers trust Hemi Metals for top-notch nickel-cobalt superalloy materials that excel under extreme thermal and mechanical conditions.
Alloy C263 Bars and Rods are primarily made up of nickel, cobalt, and chromium, with added molybdenum, titanium, and aluminum to enhance precipitation hardening. The typical composition features about 51% Ni, 20% Co, 20% Cr, 5–6% Mo, 2% Ti, and 0.6% Al. On the mechanical side, Alloy C263 boasts high tensile strength, excellent creep resistance, and impressive thermal stability up to around 900°C. It also offers outstanding oxidation resistance and dependable fatigue strength. The alloy can be solution-treated and age-hardened to achieve exceptional high-temperature mechanical properties while still being easy to form and weld.
| Standards : | AMS 5872 |
| Size Range : | 0.015″ Thk up to 2″ Thk |
| Thickness : | Range from .008″ to .0125″ |
| Length : | 2m, 2.44m, 3m, or as required |
| Width : | 10-2500mm |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Nimonic 263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Grade | Material Sheet | Temperature °C | Yield Strength 0.2 % (MPa) | Tensile Strength (MPa) | Elongation (%) | Hardness HV |
| Nimonic 263 | Nimonic 263 Round Bar Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Nimonic 263 Round Bar Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | – | |
| Nimonic 263 Round Bar Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 263 | 2.4650 | N07263 |
Yes, Alloy C263 bars are recyclable. As a high-performance alloy, it can be melted and reused for manufacturing new products, making it an environmentally friendly material in the long term.
Alloy C263 rods are available in various sizes ranging from 1/8" to 6" in diameter, with lengths typically up to 12 feet. Common finishes include hot-rolled, cold-drawn, and polished.
Yes, Alloy C263 (also known as Hastelloy C263) can be welded using appropriate techniques such as TIG or MIG welding, with careful control of heat to avoid carbide precipitation.
Alloy C263 Bars and Rods find their place in extreme-temperature and high-stress environments, making them perfect for aerospace and turbine applications. You’ll often see them in combustion chambers, turbine casings, transition ducts, exhaust systems, fasteners, and hot-section engine parts. Their superior creep and oxidation resistance at elevated temperatures make them ideal for industrial gas turbines, high-temperature springs, petrochemical processing equipment, and thermal power plant components. Alloy C263 is also a go-to choice for precision-machined parts.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hemi Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Hamilton New Zealand
